| 量程( kg) | L | H | B | M |
| 10-75 | 50.8 | 63.5 | 12.7 | M8X1.25 |
| 100-300 | 50.8 | 76.2 | 19.1 | M12X1.75 |
| 500-2000 | 50.8 | 76.2 | 25.4 | M12X1.75 |
| 2500-5000 | 50.8 | 108 | 25.4 | M18X1.5 |
| 量程Capacity | 10-5000kg |
| 精度等级Accuracy class | 0.03%F.S. |
| 额定输出Rated output | 2.0/3.0±10%mV/V |
| 零点输出Zero balance | ±0.04 mV/V |
| 非线性Non-linearity | ±0.03%F.S. |
| 滞后Hysteresis | ±0.03%F.S. |
| 重复性Repeatability | ±0.03%F.S. |
| 蠕变(30分钟)Creep(30min) | ±0.03%F.S. |
| 温度灵敏度漂移Temp.effect on output | ±0.05%F.S./10°C |
| 零点温度漂移Temp.effect on zero | ±0.05%F.S./10°C |
| 输入电阻Input impedance | 385±50Ω |
| 输出电阻Output impedance350 | ±5Ω |
| 绝缘电阻Insulation | ≥5000MΩ(50VDC) |
| 使用电压Recommended excitation | 5~10VDC |
| 最大使用电压Maximum excitation | 15VDC |
| 温度补偿范围Compensated temp. range | -10~40°C |
| 工作温度范围Operation temp. range | -20~60°C |
| 安全过载Safe overloadx | 150%F.S. |
| 极限过载Ultimate overload | 200%F.S. |
| 电缆线尺寸Cable size | Φ5x3m |
防护等级Portection class | IP65 |
