精度等级Accuracy class

0.5%F.S.

额定输出Rated output

1.0-1.5mV/V

零点输出Zero balance

±0.03 mV/V

非线性Non-linearity

±0.5%F.S.

滞后Hysteresis

±0.5%F.S.

重复性Repeatability

±0.5%F.S.

蠕变(30分钟)Creep(30min)

±0.5%F.S.

温度灵敏度漂移Temp.effect on output

±0.05%F.S./10°C

零点温度漂移Temp.effect on zero

±0.05%F.S./10°C

输入电阻Input impedance

750±50Ω

输出电阻Output impedance

700±5Ω

绝缘电阻Insulation

≥5000MΩ(50VDC)

使用电压Recommended excitation

5~10VDC

最大使用电压Maximum excitation

15VDC

温度补偿范围Compensated temp. range

-10~40°C

工作温度范围Operation temp. range

-20~60°C

安全过载Safe overload

150%F.S.

极限过载Ultimate overload

200%F.S.

电缆线尺寸Cable size

Φ5x3m

防护等级Portection class

IP67
