传感器专业制造商

精度等级Accuracy class

1%F.S.

额定输出Rated output

0.8-1.5mV/V

零点输出Zero balance

±0.1 mV/V

非线性Non-linearity

±1%F.S.

滞后Hysteresis

±1%F.S.

重复性Repeatability

±1%F.S.

蠕变(30分钟)Creep(30min)

±1%F.S.

温度灵敏度漂移Temp.effect on output

±1%F.S./10°C

零点温度漂移Temp.effect on zero

±1%F.S./10°C

输入电阻Input impedance

350±20Ω

输出电阻Output impedance

350±5Ω

绝缘电阻Insulation

≥5000MΩ(50VDC)

使用电压Recommended excitation

2.5~5VDC

最大使用电压Maximum excitation

10VDC

温度补偿范围Compensated temp. range

-10~40°C

工作温度范围Operation temp. range

-20~60°C

安全过载Safe overload

150%F.S.

极限过载Ultimate overload

200%F.S.

电缆线尺寸Cable size

Φ3x3m

防护等级Portection class

IP68
